Max.swing over bed

mm

    180

istance between centers

mm

        200/300/350

Spindle bore

mm

    20

Spindle taper

/

     MT3

Tailstock taper

/

     MT2

 Cross slide travel

mm

      65mm

 Compound travel

mm

    55

Motor output power

w

    500

Spindle speed

rpm

 100--2500

Range of threads metric

/

 0.4 - 2.0mm (10 thread pitches)

Range of threads imperial

/

12-52 TPI (8 thread pitches)

Packing size

 mm

780 x 420 x 390

N/G weight

kg

 50/55

Net weight

kw

2300/2720/3000
