High Precision Bench Lathe Machine CJM320B Turning Lathe Machine Horizontal Metal Machine Lathe Customization FM210
Factory direct sale Metal lathe horizontal lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .
| Specification | Unit | FM210 |
| Max.swing over bed | mm | 210 |
| Max.swing over cross slide | mm | 110 |
| Distance between centers | mm | 400 |
| Max. carriage travel | mm | 276 |
| Spindle speeds(Number) | r/min | 50-2500 |
| Spindle bore | mm | 21 |
| Spindle taper | / | MT2 |
| Cross slide travel | mm | 75 |
| Top slide travel | mm | 55 |
| Tailstock quill travel | mm | 60 |
| Number of spindle speed | / | Variable speed |
| Metric threads range(kinds) | / | 0.3-0.5mm (10 steps) |
| Inch threads rangs(Kinds) | / | 8-44 T.P.I. (10 steps) |
| Range of longitudinal feed | mm | 0.1~0.2 |
| Spindle motor power | w | 450W/600W 230V/1PH/50Hz |
| Brushless motor | w | 550W 230V/1PH/50Hz |
| Weight | kg | 70 |
| Machine size(L*W*H) | mm | 840x390x370 |
| Packing size | mm | 900x489x450 |
