Manual Lathe Metal Lathe Machine 1000mm Bench Metal Lathe Machine With CE FM250
Factory direct sale light duty horizontal bench lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .
Specification | Unit | FM250 |
Max.swing over bed | mm | 250 |
Max.swing over cross slide | mm | 150 |
Distance between centers | mm | 550/750 |
Bed width | mm | 135 |
Spindle speeds(Number) | r/min | 50-2500 |
Range of longitudinal feed | Mm/rev | 0.07~0.20 |
Spindle bore | mm | 26 |
Spindle taper | MT4 | |
Compound Slide Travel | mm | 60 |
Cross Slide Travel | mm | 130 |
Tailstock quill travel | mm | 60 |
Tailstock Quill Taper | MT2 | |
Metric threads range(kinds) | 0.3-0.5mm (10 steps) | |
Inch threads rangs(Kinds) | mm | 0.2-3.5 |
Range of longitudinal feed | w | 8-56 T.P.I |
Spindle motor power | w | 750 |
Net Weight | kg | 120 |
Gross weight | kg | 140 |
Packing size | mm | 1250/1450x560x570 |
