Conventional Lathe Machine

Hot Sell Manual Metal Bench Lathe Machine Cheap Price FM280

Max Swing Over Bed: 280mm

Max Work Piece Length:550/610/815mm

Spindle Power: 0.75kw(optional)

Spindle bore:26mm


  • Product Detail
  • Accessories

Hot Sell  Manual Metal Bench Lathe Machine Cheap Price FM280


Factory direct sale light duty horizontal bench lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .


Specification

Unit

 FM280

Max.swing over bed

mm

                                                                280

Max.swing over cross slide

mm

                                                                160

Distance between centers

mm

      550/610/815

Bed width

mm

   150

Spindle speeds(Number)

r/min

(12 steps )20-1200

Spindle bore

mm

      26

Spindle  taper

/

      MT4

Max. travel of cross slide

mm

    130

Max. travel of top slide

mm

    65

Max. travel of tailstock quill

mm

    60

Taper of tailstock quill

/

    MT2

Range of spindle speed



rpm

Gear drive 12 steps 80~1600rpm

Variable speed 180-2200rpm

Belt drive 6 steps 125-2000rpm

Motor power

kw

     0.75

Net weight

kgs

      190/195/202

Gross weight

kgs

220/228/238

Packing size(L*W*H)

mm

1200/1300/1400x615x640
