FC660 CNC Lathe CK6136 CK6140 CK6150 CK6166 CK6180 Horizontal CNC Metalconventional cnc Lathe Machine for sale
FAMATECH CNC LATHE is with high quality ,high precision and reasonable price , cnc lathe could do various jobs during their metalworking.the function include turning end face, taper or screws, spherical, external & internal cylindrical surfaces, and multi tool turning missions.
1.Standard 2 axis cnc lathe machine, 3rd axis is optional
2.Bed of lathe is made of heavy duty castings
3.Standard is 4 station tool turret, 6/8/12 station tool turret are optional
4. Induction hardened bed way
5.GSK control/Siemens control/ Fanuc control is available
6.Lathe up to CE certificate
7.Safety door is available
8. Pneumatic or hydraulic chuck and tailstock are available is available.
9.Servo turret and hydraulic turret are available.
10.Customer’s brand/color/voltage are customized for customer
Specification | Unit | FC800-1000/1500/2000/3000 | FC660H-1000/1500/2000/3000 | FC660-1000/1500/2000/3000 |
Distance between centers | mm | 1000/1500/2000/3000mm | 1000/1500/2000/3000mm | 750/1000/1500/2000mm |
Max. Swing over bed | mnm | 800 | 660 | 660 |
Max. Swing over cross slide | mm | 560 | 400 | 420 |
Width of bed | mm | 460 | 460 | 400 |
Bed guide hardness | HRC50 | HRC50 | HRC50 | |
Spindle type | rpm | 150-1200rpm | 150-1200rpm | 150-1600rpm*1200rpm |
Spindle speed range | 86mm,105mm | 86mm,105mm | 82mm,105mm | |
Spindle bore | mm | 70mm,90mm | 70mm,90mm | 60mm,90mm |
Max. Dia. Of through-hole | mm | A2-8 *105mmfor A2-11 | A2-8 *105mmfor A2-11 | A2-8 *105mmfor A2-11 |
Taper of spindle bore | 90mm 1:20,105mm for 115mm 1:20 | 90mm 1:20,105mm for 115mm 1:20 | ||
X axis travel | mm | 380 | 380 | 350 |
Z axis travel | mm | 1000/1500/2000/3000 | 1000/1500/2000/3000 | 750/1000/1500/2000mm |
X/Z axis rapid traverse | mm | 4/6m/min | 4/6m/min | 6/8m/min |
Chuck type | m/min | 3 jaw manual chuck *hydraulic chuck | 3 jaw manual chuck *hydraulic chuck | 3 jaw manual chuck *hydraulic chuck |
Chuck diameter | 250mm(10”),305mm(12”) | 250mm(10”),305mm(12”) | 250mm(10”),320mm(12”) | |
Turret type | mm | Electrical turret | Electrical turret | Electrical turret |
Tool position number | mm | 4(30*30mm)*6(25*25mm)*8(25*25mm) | 4(25*25mm)*6(25*25mm)*8(25*25mm) | |
Tailstock type | mm | Manual tailstock,Hydraulic tailstock | Manual tailstock,Hydraulic tailstock | |
External diameter | mm | 100mm | 100mm | 80mm |
Max. travel | mm | 235mm | 235mm | 150mm |
Taper of bore | MT5 | MT5 | MT5 | |
Spindle motor type | Variable frequency spindle motor *servo spindle motor | Variable frequency spindle motor *servo spindle motor | ||
Spindle motor power | KW | 11kw ,15kw | 7.5KW,11KW | |
Coolant pump power | W | 370W | 120W | |
Packing size(L*W*H) | mm | 3160/3660/4200/5200*2100*2350 | 3160/3660/4200/5200*2100*2280 | 2600/3050/3350/3850*1800*2220 |
Net/Gross weight | kg | 3800/4100kg 4300/4600kg 4700/5000kg 5100/5400kg | 3600/3900kg 4100/4400kg 4500/4800kg 4900/5200kg | 2950/3200 3300/3650 3550/3850 3750/4050 |
