Mechanical Lathe Machine Price Universal Horizontal Lathe Machine Price Bore 82mm or 105mm FM410/FM460

C6232/c6236/C6240 factory direct sale heavy duty horizontal lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .

Specification	Unit	FM410	FM460
Max.swing over bed	mm	410	460
Max.swing over gap	mm	735	785
Max.swing over cross slide	mm	305	355
Distance between centers	mm	1500/2000/3000
Length of gap	mm	200
Bed width	mm	350
Spindle bore	mm	80/103
Spindle taper	mm	No.7 Morse φ113 (1:20)
Spindle speeds(Number)	r/min	12 changes 25-1600r/min/25-1500r/min
Metric threads range(kinds)		47 kinds 0.2-14mm
Inch threads rangs(Kinds)		60 kinds, 2-112TPI
Moudle threads range(kinds)		34 kinds, 0.1-7MP
Diametral threads		50 kinds, 4-112TPI
Range of longitudinal feeds		35 kinds,0.059-1.646mm/rev
Range of cross feeds	mm	35 kinds,0.020-0.573mm/rev
Dia.of tailstock sleeve	mm	75
Travel of tailstock sleeve	mm/min	180
Taper of tailstock sleeve	mm	MT5
Size of tool shank	mm	25x25
Max travel of cross slide	mm	326	326 355
Max.travel of compound rest	mm	130mm
Main motor power	kw	7.5
Overall dimensions(L×W×H)	mm	2400/2850/3350/3700/4350x1150x1460	2400/2850/3350/3700/4350X1150X1510
Packing size(L×W×H)	kw	2450/2900/3400/3750/4400x1150x1740	2450/2900/3400/3750/4400x1150x1820
Net weight	kw	2150/2270/2530/2610/2930	2420/2540/2800/2880/3200
