Horizontal Manual Metalworking horizontal Lathe Machine Heavy Duty Lathe SN50 / FM500C/FM660C/FM800C

Factory direct sale heavy duty horizontal lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attchment and quick change tool post .

Specification	Unit	FM500C	FM660C	FM800C
Max.swing over bed	mm	500	660	800
Max.swing over gap	mm	710	870	1010
Max.swing over cross slide	mm	300	420	560
Distance between centers	mm	1500/2000/3000
Length of gap	mm	240
Bed width	mm	400
Spindle bore	mm	105
Spindle nose		ISO-D8
Spindle taper	mm	Metric 113
Spindle speeds(Number)	r/min	(12 steps) 36-1600rpm
Max.travel of top slide	mm	145
Max.travel of cross slide	mm	320
Max.size of toolshank	mm	25x25
Longitudinal feeds range	mm	65 kinds 0.063-2.52mm/rev
Cross feeds range	mm	65 kinds 0.027-1.07mm/rev
Metric threads range	mm	22kinds 1-14mm
Inch threads range		25kinds 28-2T.P.I
Moudle threads range		18kinds 0.5-7M.P
Diametral threads range		24kinds 56-4D.P
Dia.of tailstock sleeve	mm	75mm
Taper of tailstock		MT5
Max.travel of tailstock	mm	150mm
Main drive motor	kw	7.5
LWH	mm	2800/3300/3800/480011502200	2800/3300/3800/480011502200	3800/4300/4800/58001152200
Net weight	kg	2300 / 2700/ 3000/3300	2500/2800/3100/3400	3300/3600/3900/4200
