CW6263/CW6280/CW62100/CW62120 factory direct sale heavy duty horizontal lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.

Specification	Unit	FM630	FM800H	FM1000	FM1200
Max.swing over bed	mm	630	800	1000	1200
Max.swing over cross slide	mnm	350	485	685	800
Distance between centers	mm	1500/2000/3000/4000/5000/6000/7000/8000/9000/10000/12000
Max.swing over gap	mm	830	1000	1200	1400
Valid length of gap	mm	230
Bed width	mm	550
Spindle hole	mm	105mm OR 130mm (OPTIONAL FOR CW6180E+)
Spindle nose	mm	D-11 or C-11
Spindle taper	mm	Φ120mm Taper 1:20(Φ140， OPTIONAL FOR FM800H+）
Spindle speeds(Number)	rpm	14-750RPM(18 STEPS)
Metric threads range(kinds)	mm	1-240mm(54 kinds)
Inch threads rangs(Kinds)	inch	28-1 inch(36 kinds)
Moudle threads range(kinds)		0.5-60 DP(27 kinds)
Diametral threads range(kinds)		30-1 t.p.i.(27 kinds)
Longitudinal feeds range(kinds)	mm/r	0.048-24.3mm/r (72 kinds)
Cross feed range(kinds)	mm/r	0.024-12.15mm/r (72 kinds)
Rapid feed:Long./Cross	m/min	4/2
Cross slide travel	mm	350	420	520	620
Compound rest travel	mm	200
Size of tool shank	mm	32*32
Sleeve diameter	mm	100	100	120	110
Sleeve taper		MT6
Sleeve travel	mm	240
Main drive motor	kw	11
Coolant pump power	kw	0.09
Rapid feed motor	kw	1.1
Net/Gross weight for 1500mm	kg	4300	4500	5000	5500
