Light Duty New CQ6236 Gap Bed Horizontal Bench Lathe Machine price FM360AV/FM360DV/FM360BV

Factory direct sale heavy duty horizontal lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .

Specification	Unit	FM360AV		FM360DV		FM360BV
Max.swing over bed	mm	360
Max.swing over gap	mm	491
Max.swing over cross slide	mm	212
Distance between centers	mm	1000
Bed width	mm	187
Spindle speeds(Number)	r/min	8 steps 70-2000(51mm as 8 steps 90-2000rpm)
Spindle bore	mm	40mm (51mm as optional)
Spindle nose		D4 (51mm as D5)
Spindle taper		MT5 (51mm as MT6)
Center height	mm	178
Metric threads range(kinds)		0.4-7mm/26kinds	0.1-7mm/44kinds		0.4-7mm/32kinds
Inch threads rangs(Kinds)		4-56TPI/34kinds	4-112TPI/56kinds		4-56TPI 32kinds
Threads diametral			16-112DP/32kinds		8-120DP/32kinds
Threads module pitches			0.1-1.75MP/34kinds		0.2-3.5MP/27kinds
Compound rest travel	mm	90
Cross slide travel	mm	170
Range of longitudinal feeds		0.052-1.392mm/rev/32kinds	0.0464-3.249mm/rev(Metric ) 0.00168-0.1175in/rev（inch )		0.082-2.713mm/rev(Metric lathe) 0.0032-0.1068in/rev(inch lathe)
Range of cross feeds	mm	0.009-0.253mm/rev (metric lathe) 0.015-0.40mm/rev(inch lathe)	0.01-0.7033mm/rev(Metric lathe) 0.00046-0.3231 in/rev(inch lathe)		0.018-0.746mm/rev(Metric lathe) 0.0011-0.0367in/rev(inch lathe)
Extemal diameter	mm	32
Travel of tailstock sleeve	mm/min	100
Taper of tailstock sleeve	mm	MT3
Spindle motor power	Kw	1.5
Coolant pump power	w	40
Size of tool shank	mm	16x16
Packing size(L×W×H)	mm	1935x750x1500
Net weight	kg	600/700
