Conventional Lathe Machine

Manual Horizontal Lathe Turning Machine CQ6236 Iron Lathe Machine Price FM305


Max Swing Over Bed: 305mm

Max Work Piece Length:1000 mm

Spindle Power: 1.1kw(optional)

Spindle bore:36mm



  • Product Detail
  • Accessories

Manual Horizontal Lathe Turning Machine CQ6236 Iron Lathe Machine Price FM305

Factory direct sale horizontal bench lathe machine is with very competitive price, and is suitable for turning or cast iron and steel work piece,turning of non-ferrous metal parts of big or medium sizes.It can do external cylindrical surface turning,inner hole and end face turning.It can also turn various internal and external metric,inch,module and diametrical pitch threads,the top slide can be used independently for turning of short taper.These lathes are of high power,high rigidity and wide rotating speed range,so it can be used for high speed and strong force turning.Optional accessories include:DRO, chuck guard, toolpost guard, tin coated cutters, lead screw guard, taper turning attachment and quick change tool post .



Specification

Unit

 FM305

Max.swing over bed

mm

                                                               305

Max.swing over gap

mm

 440

Max.swing over cross slide

mm

                                                                 212

Distance between centers

mm

      530/904

Bed width

mm

    182

Spindle speeds(Number)

r/min

(12 steps )20-1200

Spindle bore

mm

      36

Spindle nose


     D4 (51mm as D5)

Spindle taper


      MT5 (51mm as MT6)

Metric threads range(kinds)


15kinds(0.25-7.5mm)

Inch threads rangs(Kinds)


40kinds(4-112T.P.I)

Range of feed amount

mm/r

       0.12-0.42mm/4(0.0047-0165)mm/r

Spindle motor power

kw

       1.1

Coolant pump power

w

        40

Packing size(L*W*H)


1420*750*760

Stands(left)(L*W*H)

mm

400*370*700(mm)

Stands(right)(L*W*H)

   mm

300*370*700(mm)

Main machine weight


365/415kgs

Stand weight

mm

 60/65kgs
